SILASTIC™
Material

Using Dow SILASTIC™ silicone and
co-extrusion manufacturering offers premium UV resistance, chemical stability, and against abrasion.

Continuous Light

One side power to drive Max.27m length in DC24V, the production length can be 30m/reel. It perfectly avoided the joints between in neon to offer you continuous and elegant light, reduced power supplies.

DIY Connector

Make the customized lengths by yourselves in minutes! Soldering free DIY connector designed for user which can support you cut our ELITE Neon and easily re-connect lead cable on site.

Different Models

Product Name
Dimension
Voltage
CCT
Power(W/M)
Efficacy@4000K
Min Cut Unit
IP Rating
Dimension:
12*20mm
Voltage:
DC24V
CCT:
color-cct 2100K-6000K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT color-digital DIGITAL
Power(W/M):
5W/10W/15W/M
Efficacy@4000K:
35.5lm/w
Min Cut Unit:
50/62.5mm
IP Rating:
IP67
Dimension:
10*18mm
Voltage:
DC24V
CCT:
color-cct 2100K-6000K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT
Power(W/M):
5W/10W/15W/M
Efficacy@4000K:
35.6lm/W
Min Cut Unit:
50/62.5mm
IP Rating:
IP67
Dimension:
16*17mm
Voltage:
DC24V
CCT:
1 2400K-6500K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT
Power(W/M):
5W/10W/15W/M
Efficacy@4000K:
73.8
Min Cut Unit:
50/71.43/83.3
IP Rating:
IP67
Dimension:
12*12mm
Voltage:
DC24V
CCT:
1 2700K-6500K color-r R color-b B color-g G rgb RGB color-cct CCT color-digital DIGITAL
Power(W/M):
5W/10W/M
Efficacy@4000K:
51.3lm/W
Min Cut Unit:
50/62.5mm
IP Rating:
IP67
Dimension:
10*10mm
Voltage:
DC24V
CCT:
color-cct 2100K-6000K color-r R color-b B color-g G
Power(W/M):
5W/10W/M
Efficacy@4000K:
66lm/W
Min Cut Unit:
35.7mm
IP Rating:
IP67
Dimension:
6*12mm
Voltage:
DC24V
CCT:
color-cct 2100K-6000K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT color-digital DIGITAL
Power(W/M):
5W/10W/M
Efficacy@4000K:
36lm/W
Min Cut Unit:
50/62.5mm
IP Rating:
IP67
Dimension:
4*8mm
Voltage:
DC24V
CCT:
1 2700K-5500K color-r R color-b B color-g G
Power(W/M):
6W/M
Efficacy@4000K:
33.8lm/W
Min Cut Unit:
50mm
IP Rating:
IP65
Dimension:
16*15mm
Voltage:
DC24V
CCT:
color-cct 2100K-6000K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT color-digital DIGITAL
Power(W/M):
5W/10W/15W/M
Efficacy@4000K:
73.0lm/W
Min Cut Unit:
50/62.5mm
IP Rating:
IP67
Dimension:
20*20mm
Voltage:
DC24V
CCT:
color-cct 2100K-6000K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT
Power(W/M):
5W/10W/15W/M
Efficacy@4000K:
46.7lm/W
Min Cut Unit:
50/62.5mm
IP Rating:
IP67
Dimension:
30*31.2mm
Voltage:
DC24V
CCT:
1 2700K-6500K color-r R color-b B color-g G rgb RGB rgbw RGBW color-cct CCT
Power(W/M):
15W/M
Efficacy@4000K:
49.5lm/W
Min Cut Unit:
50/62.5mm
IP Rating:
IP67

Application Scenarios
